Metal Transfer Gearbox with 370 Brush Motor – Premium RC Car Upgrade
Take your RC model car to the next level with this heavy-duty Metal Transfer Gearbox and 370 Brush Motor upgrade kit. Precision CNC-machined from high-grade aluminum alloy, this gearbox delivers improved durability, smoother power transfer, and better heat management compared to stock plastic components. Whether you're replacing a worn-out part or boosting your rig's performance, this is the upgrade your RC truck or crawler has been waiting for.
Key Features
- CNC Machined Aluminum Alloy – Robust, long-lasting gearbox construction built to handle demanding off-road use
- Superior Heat Dissipation – Precision motor heatsink keeps your 370 brush motor running cool during extended sessions
- Anodized Finish – Sleek, elegant look with added corrosion resistance for the mount base
- Easy Installation – Comes with all compatible screws for quick, hassle-free fitting and removal
- Direct Replacement or Upgrade – Perfect drop-in fit for a wide range of popular 1/16 scale RC trucks and crawlers
Specifications
- Motor Type: 370 Brush Motor (DC 6V max)
- Motor Diameter: 24mm
- Motor Length: 30mm
- Shaft Diameter: 3.17mm
- Axis Length: 63mm
- Gearbox Material: Aluminum Alloy
- Gearbox Color: Black
- Screws Included: 4×2.5×5mm, 1×2.5×4mm
- Package Weight: 173g
- Package Dimensions: 10 × 6 × 4 cm
Compatible Models
Designed to fit the following RC vehicles:
- WPL: B14, B16, B24, B26, B36, C14, C24
- JJRC: Q60, Q61, Q62, Q63, Q64, Q65
- MN: MN90, MN90K, MN91, MN91K, MN99S, MN D90
- FY: FY001, FY002 (4WD & 6WD)
What's in the Box
- 1 × Metal Transfer Gearbox with 370 Brush Motor
- 1 × Shaft and Screw Set
Made in Mainland China.
Note: Colors may vary slightly due to individual monitor calibration. Minor measurement differences may occur due to manual measuring.
You May Also Like
- 10-in-1 Multi-Functional Bone Wrench Hex Socket Spanner – Portable Repair Hand Tool
- 16-in-1 Multi-Function Bike Repair Tool Portable Folding Hex Wrench Set
- 3-in-1 Precision Screwdriver Keychain – Portable Mini Repair Hand Tool
Learn more: MedlinePlus on child safety
Frequently Asked Questions
Q: Is this metal gearbox compatible with the WPL B24 and WPL C24 RC trucks?
A: Yes! This metal transfer gearbox with 370 brush motor is fully compatible with WPL B24, WPL C24, and many other WPL, MN, and JJRC 1/16 scale RC trucks and crawlers listed in the compatibility section above.
Q: What is the maximum operating voltage for the 370 brush motor?
A: The 370 brush motor supports a maximum voltage of DC 6V, making it suitable for standard 1/16 scale RC car battery configurations.
Q: Does this gearbox come with all necessary hardware for installation?
A: Yes, the package includes a complete shaft and screw set (4×2.5×5mm and 1×2.5×4mm screws), so you have everything needed for a straightforward installation right out of the box.
Q: Why should I upgrade to a metal gearbox from the stock plastic one?
A: The CNC-machined aluminum alloy construction offers significantly greater durability and longevity compared to stock plastic gearboxes, especially during off-road driving. The aluminum heatsink design also helps keep the motor cooler during extended run times.
Production & Packaging Notice
To maintain high stock availability and fast shipping times, our items are sourced from multiple verified manufacturing facilities. While the core quality, materials, and product specifications remain identical, you may notice slight variations in the packaging design, manufacturing origin, or the wording of the printed instructions.
