Transparent Silicone Rubber Sheet – 500mm × 500mm
This high-performance transparent silicone rubber sheet is engineered for versatility and precision. Available in six ultra-precise thicknesses — 0.1mm, 0.2mm, 0.3mm, 0.5mm, 0.8mm, and 1mm — it is manufactured from 100% virgin silicone rubber on advanced drum-type vulcanizing presses, delivering a seamless, joint-free sheet with a consistently smooth surface and tight thickness tolerance.
Whether you need a reliable gasket material, a vacuum laminating membrane, or a high-temperature sealing film, this silicone sheet rises to the challenge. Made in Mainland China.
Key Features
- Ultra-precise thicknesses: Choose from 0.1mm, 0.2mm, 0.3mm, 0.5mm, 0.8mm, or 1mm to match your exact application.
- 100% Virgin Silicone Rubber: Translucent, non-toxic, and odorless — free from harmful substances for safe use across diverse industries.
- Wide Temperature Range: Stable performance from -60°C to +260°C (momentary peak up to 300°C).
- Excellent Chemical Resistance: Resistant to ozone, heat, oil, solvents, and corrosion for long-lasting reliability.
- High Electrical Insulation: Breakdown voltage of 4.5kV; Flammability Class V-0 for added safety.
- Smooth, Non-Stick Surface: Low surface activity prevents adhesion to other materials during use.
- Seamless Construction: Produced on super-wide drum-type presses (up to 4000mm) ensuring no joints or weak spots.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 100% Virgin Silicone Rubber |
| Size | 500mm × 500mm |
| Thickness Options | 0.1mm / 0.2mm / 0.3mm / 0.5mm / 0.8mm / 1mm |
| Color | Translucent |
| Hardness | 60 Shore A |
| Tensile Strength | 12 MPa |
| Elongation | 300% – 350% |
| Density | 1.20 ± 0.05 g/cm³ |
| Breakdown Voltage | 4.5 kV |
| Flammability Class | V-0 |
| Temperature Range | -60°C to +260°C (peak 300°C) |
| Origin | Mainland China |
Common Applications
- Custom rubber seal gaskets and flat gaskets
- PVC, wood, glass, and solar vacuum laminating presses
- Hot laminating and card laminating press membranes
- Electrical insulation films and heat-resistant barriers
- Industrial sealing, cushioning, and protective lining
Related Products You May Like
Looking for other practical tools and workshop essentials? Check out our 10-in-1 Multi-Functional Bone Wrench Hex Socket Spanner or our 16-in-1 Multi-Function Bike Repair Tool Folding Hex Wrench Set for your next project.
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What thickness of silicone rubber sheet should I choose for gasket making?
A: For general-purpose flat gaskets and sealing applications, 0.5mm to 1mm thick silicone rubber sheets are most commonly used, offering a reliable seal with good compressibility. Thinner options (0.1mm–0.3mm) are ideal for precision laminating press membranes or electrical insulation films where minimal profile is critical.
Q: Is this transparent silicone sheet safe for use with food-contact or medical-adjacent equipment?
A: This silicone rubber sheet is made from 100% virgin silicone rubber that is non-toxic and odorless. However, it is listed as an industrial-grade material. Please verify the specific regulatory requirements for your intended application before use in food-contact or sensitive environments.
Q: Can this silicone sheet handle high-temperature industrial processes?
A: Yes. This silicone rubber sheet maintains stable mechanical and electrical properties across a wide range of temperatures — from -60°C up to +260°C, with a momentary peak tolerance of 300°C — making it well-suited for hot press laminating, solar panel lamination, and similar high-temperature industrial processes.
Q: What is the surface finish of this silicone rubber sheet?
A: The sheet is available with a smooth/smooth or smooth/sand surface finish. The standard translucent variant features a smooth surface on both sides, providing consistent contact and minimal adhesion to other surfaces during processing.
